This document was generated on 03/28/2012
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
87655-0007
Active
1.27mm Pitch DDR DIMM Socket, Right Angle, Single Key, with Beveled Metal Pin and
Plastic Pegs, 184 Circuits, 0.76μm Gold (Au) Plating, 2.79mm Tail Length, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-87609-002 (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
General
LR19980
E29179
image - Reference only
EU RoHS
China RoHS
ELV and RoHS
Series
Product Family
Series
Component Type
JEDEC Outline
Product Name
Physical
Circuits (Loaded)
Color - Resin
Durability (mating cycles max)
Entry Angle
Flammability
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Voltage Key
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Product Specification
Memory Module Sockets
87655
Memory Module
MO-206
DDR DIMM
184
Black, Natural
25
90° Angle (Side Entry)
94V-0
Yes
Brass, High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
2.79mm
Yes
Yes
1.60mm
Tray
1.27mm
0.762μm
2.540μm
-10°C to +85°C
Through Hole
1A
125V
2.5V, Left
10
SMC & Wave Capable (TH only)
1
240
PS-87609-002
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
87655Series
Mates With
JEDEC standard 1.27mm modules
